Product no 1000623277
Model IFP8662
Brand ViewSonic
EAN 0766907012088
Weight 63.7 kg
Produktbeskrivelse | ViewSonic ViewBoard IFP8662 86" LED-bagbelyst LCD paneldisplay - 4K - for interaktiv kommunikation |
Produkttype | LED-bagbelyst LCD fladt paneldisplay |
Diagonal klasse | 86" |
Kommercielt brug | Ja - interaktiv |
Opløsning | 3840 x 2160 |
Display Format | 4K UHD (2160p) |
Video Grænseflade | HDMI |
HDMI Port Antal | 4 porte |
Konnektivitet | Wi-Fi (valgfri), LAN |
PC grænseflade | USB, seriel RS-232, USB 3.0, USB-C 3.1 |
LCD-baggrundsbelysningsteknik | LED baglys |
Billedformatforhold | 16:9 |
Tv-tuner | Ingen radio |
Højttalersystem | 2 højttalere, subwoofer |
Lagerkapacitet | 32 GB |
USB | Ja |
Udstyr inkluderet | Fjernstyring, 2 styluser, 8 skruer, kameraplatform, 5 klemmer, RS232 adapter |
Strømforbrug ved drift | 160 Watt |
Strømforbrugs-stand by | 0.5 Watt |
Dimensioner (B x D x H) | 196 cm x 8 cm x 117.1 cm |
Vægt | 63.7 kg |
Miljømæssige standarder | ENERGY STAR kvalificeret |
Producentgaranti | 3 års garanti |
General | |
---|---|
Combined With | Touchscreen (multi touch) / optional slot-in PC capability |
Commercial Use | Yes - interactive |
Depth | 8 cm |
Diagonal Class | 86" |
HDMI Ports Qty | 4 ports |
Height | 117.1 cm |
PC Interface | USB, serial RS-232, USB 3.0, USB-C 3.1 |
Power Consumption (Max) | 580 Watt |
Power Consumption Operational | 160 Watt |
Product Type | LED-backlit LCD flat panel display |
Protection | Tempered glass protection |
TV Tuner | No tuner |
TV Tuner Presence | No |
Video Interface | HDMI |
Weight | 63.7 kg |
Width | 196 cm |
Display | |
Additional Features | Projected Capacitive Technology (PCAP) |
Backlight Life | 30,000 hours |
Brightness | 350 cd/m² |
Coating | Anti-glare, 9H Hard |
Display Format | 4K UHD (2160p) |
Image Aspect Ratio | 16:9 |
Image Contrast Ratio | 1200:1 |
LCD Backlight Technology | LED backlight |
Resolution | 3840 x 2160 |
Response Time | 8 ms |
Touchpoints Qty | 20 |
Viewing Angle | 178° |
Viewing Angle (Vertical) | 178° |
Stands & Mounts | |
Flat Panel Mount Interface | 800 x 600 mm |
VESA Compatibility | Yes |
Media Player | |
Configuration | ARM Cortex-A73 Quad-Core ( 1.2 GHz ) - 3 GB - 32 GB |
Operating System | Android OS 8.0 |
USB Port | Yes |
Remote Control | |
Battery Included | Yes |
Type | Remote control |
Audio System | |
Output Power / Total | 29 Watt |
Speaker System | 2 speakers, subwoofer |
Speakers | 2 x main channel speaker - 12 Watt | 1 x subwoofer - 15 Watt |
Network & Internet Multimedia | |
Connectivity | Wi-Fi (optional), LAN |
LAN Protocol | Fast Ethernet |
Connections | |
Connector Type | 4 x HDMI input | HDMI output | USB-C 3.1 | 5 x USB 3.0 | USB 2.0 | Audio line-out / SPDIF output | Audio output | Gigabit LAN | LAN | RS-232 | USB 2.0 |
Miscellaneous | |
Cables Included | USB-C cable | USB cable | HDMI cable |
Compliant Standards | CB, FCC, cTUVus, REACH, ERP, Mexico Energy label, UKCA |
Included Accessories | 2 styluses, 8 screws, camera plate, 5 clamps, RS232 adapter |
Environmental Standards | |
ENERGY STAR Certified | Yes |
ENERGY STAR Version | 8.0 |
Power | |
Power Consumption Stand by | 0.5 Watt |
Power Device | Power supply |
Manufacturer Warranty | |
Service & Support | Limited warranty - parts and labor - 3 years - on-site | Limited warranty - backlight - 3 years - on-site |
Dimensions & Weight (Shipping) | |
Depth (Shipping) | 27 cm |
Height (Shipping) | 129 cm |
Weight (Shipping) | 84.3 kg |
Width (Shipping) | 211.3 cm |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Max Operating Temperature | 40 °C |
Min Operating Temperature | 0 °C |
