Slank, indendørs/udendørs Wi-Fi 6 access point designet til mesh-applikationer.
Product no 1000576004
Model U6-MESH
Brand
Go to brand's website
EAN 0810010078278
Weight 1.02 kg
Model | U6 Mesh |
Type | Trådløs forbindelse |
Antal pakker | 1 |
Mesh-netværk | Ja |
Trådløs protokol | 802.11ax |
WiFi-bånd | 2.4 GHz, 5 GHz |
Dataoverførselshastighed | 5300 Mbps |
Antenneformfaktor | Intern |
Antal antenner | 4 |
Direktivitet | Omni-directional |
Forstærkning | 5 dB |
Liniekodningsformat | OFDMA |
Forbindelsesteknologi | Kabling, Trådløs |
Interface | 1 - RJ-45 |
Dataforbindelsesprotokol | Gigabit Ethernet |
Type | Strøminjektor, MIPS 1004KEc |
Strømforbrug ved drift | 11.4 W |
Farvekategori | Hvid |
Clock-frekvens | 0.88 GHz |
Statusindikatorer | Link, Status |
Kapacitet | BSSIDs per radio: 8 |
Processor type | MIPS 1004KEc |
Type | Ubiquiti UniFi Software |
Egenskaber | Monterbar på loft, Monterbar på stang, Til vægmontering, IPX5 |
Medfølgende ledninger | Monteringspakke, PoE injektor |
Min. driftstemperatur | -30 °C |
Maks. driftstemperatur | 60 °C |
Fugtighedsgrad ved brug | 5 - 95 % (ikke-kondenserende) |
Krypterings algoritme | WPA, WPA2, WPA3 |
Bredde | 4.85 cm |
Højde | 15.95 cm |
Vægt | 400 g |
Type | 1 års garanti |
General | |
---|---|
Depth | 4.85 cm |
Device Type | Wireless access point |
Height | 15.95 cm |
Ruggedized Design | Outdoor, indoor |
Weight | 400 g |
Width | 4.85 cm |
Networking | |
Authentication Method | Basic Service Set Identifier (BSSID) |
Capacity | Number of concurrent clients: 300+ | BSSIDs per radio: 8 |
Compliant Standards | IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax |
Connectivity Technology | Wireless |
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
Data Transfer Rate | 5.3 Gbps |
Encryption Algorithm | WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise, WPA3-PSK |
Features | VLAN support, manageable, firmware upgradable, wall mountable, Mesh networking, reset button, pole mountable, 4x4 MU-MIMO technology, Advanced QoS, waterproof, 2x2 MIMO technology, Guest Isolation, Bluetooth management |
Form Factor | External |
Frequency Band | 2.4 GHz, 5 GHz |
Performance | Maximum data rate (2.4 GHz): 573.5 Mbps | Maximum data rate (5 GHz): 4.8 Gbps |
Spread Spectrum Method | OFDMA |
Antenna | |
Antenna | Internal |
Expansion / Connectivity | |
Interfaces | 1 x 1000Base-T (PoE) - RJ-45 |
Miscellaneous | |
Compliant Standards | Plug and Play, IC, FCC, IPX5 |
Included Accessories | Pole/wall mount kit |
Power | |
Power Device | Power injector |
Power Over Ethernet (PoE) Supported | PoE |
Environmental Parameters | |
Humidity Range Operating | 5 - 95% (non-condensing) |
Max Operating Temperature | 60 °C |
Min Operating Temperature | -30 °C |
