Product no 998966141
Model TL-SG1210MP
Brand
Go to brand's website
EAN 6935364052683
Weight 1.58 kg
Produktbeskrivelse | TP-Link TL-SG1210MP V2 - switch - 10 porte - ikke administreret |
Enhedstype | Switch - 10 porte - ikke administreret |
Undertype | Gigabit Ethernet |
Porte | 8 x 10/100/1000 (PoE+) + 1 x 10/100/1000 (uplink) + 1 x Gigabit SFP (uplink) |
Power Over Ethernet (PoE) | PoE+ |
Præstation | Båndbredde: 20 Gbps<br>Pakkevideresendelseshastighed: 14.88 Mpps |
MAC adresse table størrelse | 4K indtastningshukommelse |
Jumborammesupport | 16KB |
Egenskaber | Datatransport, auto-negotiation, auto-uplink (auto MDI/MDI-X), gem og send, blæserløs, prioritetstilstand, forlængelsestilstand |
Overensstemmelsesstandarder | IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at |
Dimensioner (B x D x H) | 20.9 cm x 12.6 cm x 2.6 cm |
General | |
---|---|
Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at |
Device Type | Switch - 10 ports - unmanaged |
Enclosure Type | Desktop, wall-mountable |
Features | Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, fanless, priority mode, extend mode |
Jumbo Frame Support | 16KB |
MAC Address Table Size | 4K entries |
Performance | Bandwidth: 20 Gbps | Packet forwarding rate: 14.88 Mpps |
Ports | 8 x 10/100/1000 (PoE+) + 1 x 10/100/1000 (uplink) + 1 x Gigabit SFP (uplink) |
Power Over Ethernet (PoE) | PoE+ |
Status Indicators | Power, PoE, link/activity, PoE max |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 8 x 1000Base-T RJ-45 PoE+ | 1 x 1000Base-T RJ-45 uplink | 1 x Gigabit LAN SFP uplink |
Power | |
Power Device | External power adapter |
Power Provided | 53.5 V - 2.43 A |
Miscellaneous | |
Compliant Standards | FCC, RoHS |
Dimensions & Weight | |
Depth | 12.6 cm |
Height | 2.6 cm |
Width | 20.9 cm |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Humidity Range Storage | 5 - 90% (non-condensing) |
Max Operating Temperature | 40 °C |
Max Storage Temperature | 70 °C |
Min Operating Temperature | 0 °C |
Min Storage Temperature | -40 °C |
