Product no 988493318
Model USB31000SPTB
Brand StarTech.com
EAN 0065030851893
Weight 0.12 kg
Produktbeskrivelse | StarTech.com USB 3.0 Ethernet Adapter - USB 3.0 Network Adapter NIC with USB Port - USB to RJ45 - USB Passthrough (USB31000SPTB) - netværksadapter - USB 3.0 - Gigabit Ethernet |
Enhedstype | Netværksadapter |
Model | Ekstern |
Grænseflade (bus) type | SuperSpeed USB 3.0 |
Porte | Gigabit Ethernet |
Dimensioner (B x D x H) | 3.5 cm x 8.2 cm x 1.7 cm |
Vægt | 50 g |
Kabeltype | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
Dataforbindelsesprotokol | 10Mb LAN, 100Mb LAN, 1GbE |
Processor | ASIX AX88179 |
Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x |
Farve | Sort |
Systemkrav | Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Linux Kernel 2.6.25 eller senere, Google Chrome OS 55 eller senere, Microsoft Windows Server 2019, kun Linux LTS-versioner, Apple MacOS X 10.6 - 10.15, Microsoft Windows XP / Vista / 7 / 8 / 8.1 / 10 / 11, Apple MacOS 11.3 eller nyere |
Producentgaranti | 2 års garanti |
Designet for | P/N: TB33A1C |
General | |
---|---|
Device Type | Network adapter |
Form Factor | External |
Interface (Bus) Type | SuperSpeed USB 3.0 |
Networking | |
Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x |
Connectivity Technology | Wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Features | Flow control, full duplex capability, auto-uplink (auto MDI/MDI-X), USB powered, IPv4 and IPv6 Large Send Offload and Checksum Offload (LSO/TCO), Jumbo Frames support, VLAN Tagging (not supported in MacOS) |
Ports | Gigabit Ethernet |
Status Indicators | Port transmission speed, link/activity |
Processor / Memory | |
Processor | ASIX AX88179 |
Expansion / Connectivity | |
Interfaces | 1 x 1000Base-T - RJ-45 - female | 1 x USB 3.0 - 9 pin USB Type A - female |
Miscellaneous | |
Cables Included | 1 x USB cable (integrated) - 15.24 cm |
Color | Black |
Compliant Standards | FCC, RoHS |
Software / System Requirements | |
OS Required | Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Linux Kernel 2.6.25 or later, Google Chrome OS 55 or later, Microsoft Windows Server 2019 |
Software Included | Drivers & Utilities |
Dimensions & Weight | |
Depth | 8.2 cm |
Height | 1.7 cm |
Weight | 50 g |
Width | 3.5 cm |
Manufacturer Warranty | |
Service & Support | Limited warranty - 2 years |
Environmental Parameters | |
Humidity Range Operating | 5 - 85% |
Max Operating Temperature | 50 °C |
Min Operating Temperature | 0 °C |
Compatibility Information | |
Designed For | P/N: TB33A1C |
