Product no 993203890
Model CRS112-8P-4S-IN
Brand MikroTik
EAN 2000000968285
Weight 1.54 kg
Produktbeskrivelse | MikroTik Cloud Router Switch CRS112-8P-4S-IN - switch - 12 porte - Administreret - monterbar på stativ |
Enhedstype | Switch - 12 porte - L3 - Administreret |
Pakningstype | Monterbar på stativ |
Undertype | Gigabit Ethernet |
Porte | 8 x 10/100/1000 (PoE) + 4 x SFP |
Power Over Ethernet (PoE) | PoE+ |
Præstation | Non-blocking switching-kapacitet: 12 Gbps<br>Omkoblingskapacitet: 24 Gbps<br>Videresendelseshastighed: 17.8 Mpps |
Kapacitet | Samtidige VLANs: 4000 |
Jumborammesupport | 9204 byte |
Egenskaber | Auto-sensing per device, VLAN-understøttet, portspejling, Broadcast Storm Control, RSTP support, ACL support, blæserløs, portisolering, Static Link Aggregation, routertilstand |
Overensstemmelsesstandarder | IEEE 802.1Q, IEEE 802.3af, IEEE 802.3at |
Effekt | DC 18 - 57 V |
Dimensioner (B x D x H) | 20 cm x 14.3 cm x 4 cm |
General | |
---|---|
Capacity | Simultaneous VLANs: 4000 |
Compliant Standards | IEEE 802.1Q, IEEE 802.3af, IEEE 802.3at |
Device Type | Switch - 12 ports - L3 - managed |
Enclosure Type | Desktop, rack-mountable |
Features | Auto-sensing per device, VLAN support, port mirroring, Broadcast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, Access Control List (ACL) support, fanless, port isolation, Static Link Aggregation, router mode |
Flash Memory | 16 MB |
Jumbo Frame Support | 9204 bytes |
Performance | Non-blocking switching capacity: 12 Gbps | Switching capacity: 24 Gbps | Forwarding rate: 17.8 Mpps |
Ports | 18 x 10/100/1000 (PoE) + 4 x SFP |
Power Over Ethernet (PoE) | PoE+ |
Processor | 1: 400 MHz |
RAM | 128 MB |
Remote Management Protocol | SNMP |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 1 x serial RJ-45 | 8 x 1000Base-T RJ-45 PoE+ | 4 x SFP |
Power | |
Power Consumption Operational | 10 Watt |
Power Device | Internal power supply |
Voltage Required | DC 18 - 57 V |
Software / System Requirements | |
Software Included | MikroTik RouterOS (licence level 5) |
Dimensions & Weight | |
Depth | 14.3 cm |
Height | 4 cm |
Width | 20 cm |
Environmental Parameters | |
Max Operating Temperature | 60 °C |
Min Operating Temperature | -20 °C |
