Product no 1000464369
Model 02329-001
Brand Axis Communications
EAN 7331021075955
Weight 0.8 kg
Produktbeskrivelse | AXIS P3267-LV - netværksovervågningskamera - kuppel |
Enhedstype | Netværksovervågningskamera - fast - kuppel - indendørs - beskyttet mod vandalisme |
Audio | Ja |
Dimensioner (B x D x H) | 14.9 cm x 14.9 cm x 10.7 cm |
Vægt | 800 g |
Farve | Hvid |
Connectivity teknologi | Med ledning |
Kamera | Farve - Dag/nat |
Optisk zoom | 2.7 x |
Maksimum opløsning | 2592 x 1944 |
Billedhastighed (maks.) | 30 frames pr. sekund |
Bevægelsesdetektion | Ja |
Billedsensortype | CMOS - 1/2.7" - 5 MP |
Minimumbelysning | 0.13 lux - farve - F1.3 - 50 IRE<br>0 lux - IR - F1.3 |
Brændviddekontrol | Forskellige brændvidder |
Brændvidde | 3 mm - 8 mm |
Fokusindstilling | (mindsteafstand 1 m) |
Objektiv Iris | F/1.3 - manuel irisblænder |
Poanoreringsvinkel (grad) | -190 to +190 |
Krængningsvinkel (grad) | -10 til +80 |
Interface | Ethernet 10Base-T/100Base-TX |
Spænding | PoE Class 3 |
Egenskaber | Multi-streaming, digital PTZ-funktion, Variable Bitrate (VBR), OptimizedIR, Zipstream-teknologi, fjernfokus, Forensic WDR, HTTP-kryptering, underskrevet firmware, sikker støvle, Adaptive Bitrate (ABR), Lightfinder 2.0 teknologi, polykarbonat-kabinet, afrimning, dagshold, nathold, fjernzoom, Axis Edge Vault, Multi-Bitrate (MBR) |
Producentgaranti | 5 års garanti |
Miljømæssige parametre (operativ) | 0 °C - 50 °C; 10 - 85% RH (non-condensing) relativ luftfugtighed |
General | |
---|---|
Audio Formats | PCM, G.726, ADPCM, AAC-LC, LPCM, G.711, OPUS |
Audio Support | Yes |
Connectivity Technology | Wired |
Depth | 14.9 cm |
Device Type | Network surveillance camera |
Form Factor | Dome |
Height | 10.7 cm |
Localization | Chinese (traditional), Chinese (simplified), English, German, French, Italian, Portuguese, Polish, Russian, Spanish, Japanese, Korean / Argentina, Australia, China, Japan, Korea, Brazil, United Kingdom, United States, Europe |
Weight | 800 g |
Width | 14.9 cm |
Camera | |
Digital Video Capture Resolution | 160 x 90 |
Digital Video Format | H.264, H.265 |
Exposure Range | 1/5 sec - 1/33500 sec |
Features | Multi-streaming, digital PTZ function, Variable Bitrate (VBR), OptimizedIR, Zipstream technology, remote focus, Forensic WDR, HTTPs encryption, signed firmware, secure boot, Adaptive Bitrate (ABR), Lightfinder 2.0 technology, polycarbonate housing, d |
Flash Memory | 8 GB |
Frame Rate (max) | 30 frames per second |
Infrared Distance | 40 m |
Infrared LEDs | Yes |
Max Digital Video Resolution | 2592 x 1944 |
Minimum Illumination | 0.13 lux - color - F1.3 - 50 IRE | 0 lux - IR - F1.3 |
Motion Detection | Yes |
RAM | 2 GB |
Supported Image Formats | JPEG (Motion photos) |
Type | Color - Day&Night - fixed - indoor - vandal-proof |
Image Sensor | |
Type | 5 MP CMOS 1/2.7" |
Lens Construction | |
Focal Length | 3 mm - 8 mm |
Horizontal Field of View (degree) | 40 - 104 |
Lens Iris | F/1.3 manual iris |
Min Focus Distance | 1 m |
Optical Zoom | 2.7 x |
Type | Vari-focal |
Vertical Field of View (degree) | 29 - 74 |
Panning | |
Range (degree) | -190 to +190 |
Tilting | |
Range (degree) | -10 to +80 |
Interfaces | |
Network Interface | Ethernet 10Base-T/100Base-TX |
Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, QOS, IGMPv2, IGMPv3, CIFS, SRTP, SFTP, SIP, LLDP, Zeroconf, USGv6, MQTT, CDP, Sy |
Expansion / Connectivity | |
Ports | LAN/power - RJ-45 | Digital input/output - terminal block |
Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
Miscellaneous | |
Color | White |
Compliant Standards | EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, FCC Part 15 B Class A, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, EN 50121-4, IEC 62236-4, VCCI Class A, RCM, IS13252, KN35, AS/NZS CISPR 32 Cla |
Included Accessories | Cable gaskets, drill hole template, connector guard, Resitorx TR20 screw bit, terminal block connectors |
Power | |
Power Device | 6.4 Watt |
Power Requirements | PoE Class 3 |
Software / System Requirements | |
Software Included | AXIS Camera Station, Windows decoder 1-user license, AXIS Companion, AXIS Video Motion Detection, AXIS Object Analytics |
Manufacturer Warranty | |
Service & Support | Limited warranty - 5 years |
Environmental Parameters | |
Max Operating Temperature | 50 °C |
Min Operating Temperature | 0 °C |
Relative Humidity (operating) | 10 - 85% RH (non-condensing) |
