AXIS M3216-LVE Netværksovervågningskamera Fast irisblænder Udendørs 2688 x 1512
AXIS M3216-LVE - Netværksovervågningskamera - kuppel - udendørs - vandal / vandtæt - farve (Dag/nat) - 4 MP - 2688 x 1512 - fast irisblænder - fast brændvidde - audio - LAN 10/100 - MJPEG, H.264, H.265, MPEG-4 Part 10, MPEG-H Part 2 - DC 12 V / PoE
5 676,00DKK4 540,80DKK excl. VAT
-
Product no 1000696458
Model 02372-001
Brand Axis Communications
EAN 7331021076556
Weight 0.791 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | AXIS M3216-LVE - netværksovervågningskamera - kuppel |
| Enhedstype | Netværksovervågningskamera - fast - kuppel - udendørs - vandal / vandtæt |
| Audio | Ja: indbygget mikrofon, tovejs audio via kant til kant-teknologi |
| Dimensioner (B x D x H) | 14.9 cm x 14.9 cm x 10.2 cm |
| Vægt | 791 g |
| Farve | Hvid, NCS S 1002-B |
| Connectivity teknologi | Med ledning |
| Kamera | Farve - Dag/nat |
| Maksimum opløsning | 2688 x 1512 |
| Billedhastighed (maks.) | 60 frames pr. sekund |
| Bevægelsesdetektion | Ja |
| Billedsensortype | PS RGB CMOS - 1/2.7" - 4 MP |
| Minimumbelysning | 0.16 lux - farve - F2.0 - 50 IRE<br>0 lux - S/H - F2.0 - 50 IRE - infrarøde LEDer på |
| Brændviddekontrol | Fast brændvidde |
| Brændvidde | 2.9 mm |
| Objektiv Iris | F/2.0 - fast irisblænder |
| Poanoreringsvinkel (grad) | -190 to +190 |
| Krængningsvinkel (grad) | -10 til +80 |
| Interface | Ethernet 10Base-T/100Base-TX |
| Spænding | DC 12 V / PoE |
| Egenskaber | Skarphedskontrol, hvidbalance, mætningskontrol, lysstyrkekontrol, solblænde, kontrastkontrol, e-mail advarsler, spejlbillede, Wide Dynamic Range (WDR), digital PTZ-funktion, kodeordsbeskyttelse, Variable Bitrate (VBR), Zipstream-teknologi, Access Control, ONVIF (Profil S) support, ONVIF (Profile G) support, billedskabelon, plastikkabinet, infrarødt skåret filter, digest-autentificering, Forensic WDR, IP-adressefiltrering, eksponeringszone, HTTP-kryptering, underskrevet firmware, sikker støvle, ONVIF (Profile T) support, Adaptive Bitrate (ABR), afrimning, kompression, polygon-fortrolighedsmaske, 180° billedrotation, 90° billedrotation, 270° billedrotation, brugeradgangslog, centraliseret certifikatsadministration, råstyrkeforsinkelsesbeskyttelse, dagshold, nathold, ONVIF (Profile M) support, Axis Edge Vault, Multi-Bitrate (MBR), Axis-enheds-ID, sikker keystore, videostreaming-indikator, dyb læring-behandlingsenhed (DLPU), dynamisk tekstskabelon, VoIP-support, tonekortlægning, eksponeringstilstand, tromleforvrængningskorrektion, netværkshøjttalerparring |
| Producentgaranti | 5 års garanti |
| Miljømæssige parametre (operativ) | -40 °C - 50 °C; 5 - 95% RH (non-condensing) relativ luftfugtighed |
| General | |
|---|---|
| Audio Formats | AAC, LPCM, G.711, OPUS |
| Audio Support | Yes: built-in microphone, two-way audio via edge-to-edge technology |
| Connectivity Technology | Wired |
| Depth | 14.9 cm |
| Device Type | Network surveillance camera |
| Form Factor | Dome |
| Height | 10.2 cm |
| Localization | Chinese (traditional), Chinese (simplified), English, German, French, Italian, Portuguese, Polish, Russian, Spanish, Japanese, Korean |
| Weight | 791 g |
| Width | 14.9 cm |
| Camera | |
| Digital Video Capture Resolution | 160 x 120, 2304 x 1728, 2688 x 1512, 160 x 90 |
| Digital Video Format | MJPEG, H.264, H.265, MPEG-4 Part 10, MPEG-H Part 2 |
| Exposure Range | 1/5 sec - 1/50000 sec |
| Features | Sharpness control, white balance, saturation control, brightness control, sunshield, contrast control, e-mail alerts, image mirror, Wide Dynamic Range (WDR), digital PTZ function, password protection, Variable Bitrate (VBR), Zipstream technology, Acc |
| Flash Memory | 8192 MB |
| Frame Rate (max) | 60 frames per second |
| Infrared Distance | 30 m |
| Max Digital Video Resolution | 2688 x 1512 |
| Minimum Illumination | 0.16 lux - color - F2.0 - 50 IRE | 0 lux - B&W - F2.0 - 50 IRE - infrared LEDs on |
| Motion Detection | Yes |
| RAM | 1024 MB |
| Type | Color - Day&Night - fixed - outdoor - vandal / waterproof |
| Image Sensor | |
| Type | 4 MP PS RGB CMOS 1/2.7" |
| Lens Construction | |
| Focal Length | 2.9 mm |
| Horizontal Field of View (degree) | 102 |
| Lens Iris | F/2.0 fixed iris |
| Type | Fixed focal |
| Vertical Field of View (degree) | 73 |
| Panning | |
| Range (degree) | -190 to +190 |
| Tilting | |
| Range (degree) | -10 to +80 |
| Interfaces | |
| Alarm Inputs Qty | 1 |
| Alarm Outputs Qty | 1 |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, QOS, IGMPv2, IGMPv3, CIFS, SRTP, EAP, SFTP, SIP, LLDP, Zeroconf, USGv6, MQTT, CD |
| Expansion / Connectivity | |
| Ports | LAN/power - RJ-45 | Audio line-in/microphone - 3.5 mm jack | Digital input/output - terminal block |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous | |
| Color | White, NCS S 1002-B |
| Compliant Standards | EN 61000-6-1, NEMA Type 4X, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, EAL 4, FCC Part 15 B Class A, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, VCCI Class A, RCM, IEC 62471, AS/NZS CISPR 32 Class A, KN32 Class A, EN 55032 Class A |
| Included Accessories | Cable gaskets, drill hole template, weathershield, connector guard, Resitorx TR20 screw bit, terminal block connectors |
| Power | |
| Power Device | 4.8 Watt |
| Power Requirements | DC 12 V / PoE |
| Software / System Requirements | |
| Software Included | AXIS Camera Station, Windows decoder 1-user license, AXIS Companion |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | |
| Max Operating Temperature | 50 °C |
| Min Operating Temperature | -40 °C |
| Relative Humidity (operating) | 5 - 95% RH (non-condensing) |
