Product no 1000812121
Model 90-MXBKA0-A0UAYZ
Brand
Go to brand's website
EAN 4710483940965
Weight 1.48 kg
Produktbeskrivelse | ASRock Z790 PG Lightning - bundkort - ATX - LGA1700 sokkel - Z790 |
Produkttype | Bundkort - ATX |
Chipsættype | Intel Z790 |
Processor-socket | 1 x LGA1700 sokkel |
Kompatible processorer | (understøtter 12th og 13th Generation Intel Core/Pentium Gold/Celeron) |
Max RAM-størrelse | 128 GB |
RAM understøttet | 4 DIMM åbninger - DDR5, ikke-ECC, ikke bufferet |
Lagringsporte | 4 x SATA-600 (RAID), 4 x Hyper M.2 |
USB / FireWire porte | 1 x USB-C 3.2 Gen 2x2 + 1 x USB 3.2 Gen 2 + 5 x USB 3.2 Gen 1 + 1 x USB 2.0 + (1 x USB-C 3.2 Gen 1 + 4 x USB 3.2 Gen 1 + 2 x USB 2.0 via samlekasser) |
Audio | HD Audio (8-kanaler) |
LAN | 2.5 Gigabit Ethernet |
General | |
---|---|
Chipset Type | Intel Z790 |
Compatible Processors | (supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron) |
Max Processors Qty | 1 |
Processor Socket | LGA1700 Socket |
Product Type | Motherboard - ATX |
Supported RAM | |
Bus Clock | 4800 MHz (O.C.), 5600 MHz (O.C.), 6000 MHz (O.C.), 4000 MHz, 4800 MHz, 6800 MHz (O.C.), 3600 MHz, 4400 MHz |
Features | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) 3.0 |
Max Size | 128 GB |
Registered or Buffered | Unbuffered |
Supported RAM Integrity Check | Non-ECC |
Technology | DDR5 |
Audio | |
Audio Codec | Realtek ALC897 |
Compliant Standards | High Definition Audio |
Type | HD Audio (8-channel) |
LAN | |
Network Controller | Dragon RTL8125BG |
Network Interfaces | 2.5 Gigabit Ethernet |
Expansion / Connectivity | |
Expansion Slots | 1 x CPU | 4 x DIMM 288-pin | 1 x PCIe 5.0 x16 | 1 x PCIe 4.0 x16 (x4 mode) | 3 x PCIe 3.0 x1 | 1 x M.2 socket (2230 M.2 Key E slot) | 3 x M.2 socket (2260/2280 M.2 Key M slot) | 1 x M.2 socket (2242/2260/2280 M.2 Key M slot) |
Interfaces | 1 x HDMI | 1 x USB 2.0 | 1 x USB-C 3.2 Gen2x2 | 1 x USB 3.2 Gen 2 | 5 x USB 3.2 Gen 1 | 1 x LAN (2.5Gigabit Ethernet) | 1 x PS/2 keyboard / mouse | 1 x microphone - mini-jack | 1 x audio line-in - mini-jack | 1 x audio line-out - mini-jack |
Internal Interfaces | 1 x USB-C 3.2 Gen 1 - header | 4 x USB 3.2 Gen 1 - header | 2 x USB 2.0 - header | 1 x audio - header | 1 x Thunderbolt - header | 1 x SPI - header | 1 x Embedded DisplayPort (eDP) - header |
Power Connectors | 24-pin main power connector, 2 x 8-pin ATX12V connectors |
Storage Interfaces | SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 | PCIe 4.0 -connectors: 3 x M.2 - RAID 0 / RAID 1 / RAID 5 | SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 5 |
Features | |
BIOS Features | UEFI BIOS |
BIOS Type | AMI |
Hardware Features | ATI CrossFire technology support, ASRock Instant Flash, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Easy RAID Installer, 6 Layer PCB, Dr.MOS MOSFET, ASRock EZ Mode, Hi-Density Power Connectors, Water Pump Header, pre-mounted I/O shield, |
Miscellaneous | |
Cables Included | 2 x Serial ATA cable |
Compliant Standards | EuP Ready, ErP Ready, HDCP 2.3 |
Depth | 24.4 cm |
Included Accessories | Standoff for M.2 socket, 5 x M.2 screws |
Software Included | ASRock Phantom Gaming Tuning, ASRock Phantom Gaming LAN Software |
Width | 30.5 cm |
