ASPOWER U2A-B20600-S Strømforsyning 600Watt
ASPOWER U2A-B20600-S - Strømforsyning (intern) - AC 100-240 V - 600 Watt
1 138,00DKK910,40DKK excl. VAT
-
Product no 992921164
Model 88887228
Brand Inter-Tech Elektroni
EAN 4260455642279
Weight 1.94 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | ASPOWER U2A-B20600-S - strømforsyning - 600 Watt |
| Enhedstype | Strømforsyning - intern |
| Vægt | 1.69 kg |
| Indgangspænding | AC 100-240 V |
| Udgangspænding | +3.3, +5, ±12 V |
| Strømkapacitet | 600 Watt |
| Output Current | +3.3V - 25 A<br>+5V - 25 A<br>+12V - 48 A<br>-12V - 0.5 A<br>+5VSB - 3 A |
| Output-stikforbindelser | 1 x strøm 24 pin ATX med aftagelig 4 pin sektion<br>1 x strøm 8 pin +12 V med aftagelig 4 pin sektion<br>2 x 15 pin Serial ATA strøm<br>6 x 4-PIN intern strøm<br>1 x 4-PIN mini-strømforsyningsforbinder |
| Kølesystem | 80 mm ventilator |
| Dimensioner (B x D x H) | 10 cm x 22.5 cm x 7 cm |
| Producentgaranti | 3 års garanti |
| General | |
|---|---|
| Device Type | Power supply - internal |
| Power Device | |
| Efficiency | 90% |
| Frequency Required | 50/60 Hz |
| Input Voltage | AC 100-240 V |
| Output Current | +3.3V - 25 A | +5V - 25 A | +12V - 48 A | -12V - 0.5 A | +5VSB - 3 A |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 600 Watt |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section | 1 x power 8 pin +12V with detachable 4 pin section | 2 x 15 pin Serial ATA power | 6 x 4 pin internal power | 1 x 4 pin mini-power connector |
| Miscellaneous | |
| Cooling System | 80 mm fan |
| Features | Overheat protection, overcurrent protection, overvoltage protection, overpower protection, short-circuit protection, fan speed control |
| MTBF | 100,000 hours |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Dimensions & Weight | |
| Depth | 22.5 cm |
| Height | 7 cm |
| Weight | 1.69 kg |
| Width | 10 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 1.95 kg |
