Product no 1000794607
Model SRTL3000RM4UXLI-NC
Brand APC
EAN 0731304509004
Weight 44.5 kg
Produktbeskrivelse | APC Smart-UPS On-Line - UPS - 2700 Watt - 3000 VA - med APC UPS Network Management Card |
Enhedstype | UPS - rackversion |
Ledningslængde | 1.83 m |
Rackstørrelse | 4U |
Vægt | 44.5 kg |
Indgangspænding | AC 220/230 V |
Udgangspænding | AC 220/230 V |
Strømkapacitet | 2700 Watt / 3000 VA |
Input-stik | 1 x strøm IEC 60320 C20 |
Output-stikforbindelser | 6 x power IEC 60320 C13<br>2 x strøm IEC 60320 C19 |
Batteri | Litium-ion |
Netværk | USB, Ethernet 10/100/1000, serial |
Farve | Sort, sølv |
Dimensioner (B x D x H) | 43.2 cm x 63.9 cm x 17.1 cm |
Producentgaranti | 5 års garanti |
Bundtet med | APC UPS Network Management Card |
General | |
---|---|
Bundled with | APC UPS Network Management Card |
Color | Black, silver |
Cord Length | 1.83 m |
Device Type | UPS - rack-mountable |
Height (Rack Units) | 4U |
Power Device | |
Frequency Provided | 50/60 Hz ± 3Hz |
Frequency Required | 40 - 70 Hz |
Input Connectors | 1 x power IEC 60320 C20 |
Input Voltage | AC 220/230 V |
Input Voltage Range | AC 160 - 275 V |
Output Voltage | AC 220/230 V 50/60 Hz |
Output Waveform | Sinewave |
Power Capacity | 2700 Watt / 3000 VA |
Power Output Connectors Details | 6 x power IEC 60320 C13 | 2 x power IEC 60320 C19 |
Surge Energy Rating | 432 Joules |
Surge Suppression | Yes |
UPS Technology | On-line |
Battery | |
Technology | Lithium ion |
Networking | |
Remote Management Interface | USB, Ethernet 10/100/1000, serial |
Expansion / Connectivity | |
Expansion Slots | 1 (total) / 1 (free) x SmartSlot |
Interfaces | 1 x management (USB) - 4 pin USB Type B | 1 x EPO (emergency power off) | 1 x serial - RJ-45 | 2 x universal I/O port | 2 x management (USB) - 4 pin USB Type A | 1 x console |
Miscellaneous | |
Cables Included | Power cable 1.83 m |
Compliant Standards | IP20 |
Features | High density, vertical mount, horizontal mount, audible alarm, LCD display, built-in static bypass, vertical orientation, horizontal orientation, visible alarm, double conversion |
Rack Mounting Kit | Included |
Manufacturer Warranty | |
Service & Support | Limited warranty - replace or repair - 5 years |
Environmental Parameters | |
Humidity Range Operating | 0 - 95% RH (non-condensing) |
Max Operating Temperature | 40 °C |
Min Operating Temperature | 0 °C |
Sound Emission | 50 dBA |
Dimensions & Weight | |
Depth | 63.9 cm |
Height | 17.1 cm |
Weight | 44.5 kg |
Width | 43.2 cm |
