Product no 995278866
Model AK-T1-250
Brand Akyga
EAN 5901720135612
Weight 0.88 kg
Produktbeskrivelse | Akyga Ultimate Series AK-T1-250 - strømforsyning - 250 Watt |
Enhedstype | Strømforsyning - aktiv Power Factor Correction (PFC) - intern |
Specifikationsoverensstemmelse | TFX12V |
80 PLUS certificering | 80 PLUS Gold |
Vægt | 836.4 g |
Indgangspænding | AC 230 V |
Udgangspænding | +3.3, +5, +12 V |
Strømkapacitet | 250 Watt |
Output Current | +3.3V - 15 A<br>+5V - 15 A<br>+12V - 16 A |
Input-stik | 1 x strøm IEC 60320 C14 |
Output-stikforbindelser | 1 x strøm 24 pin ATX<br>1 x strøm 8 pin EPS12 V med aftagelig 4 pin ATX12V sektion<br>3 x 15 pin Serial ATA strøm |
Kølesystem | 80 mm ventilator |
Farve | Grå |
Dimensioner (B x D x H) | 8.5 cm x 17.5 cm x 6.5 cm |
Producentgaranti | 2 års garanti |
General | |
---|---|
Color | Gray |
Device Type | Power supply - active Power Factor Correction (PFC) - internal |
PSU Form Factor | TFX |
Specification Compliance | TFX12V |
Power Device | |
80 PLUS Certification | 80 PLUS Gold |
Efficiency | 80%+ |
Input Connectors | 1 x power IEC 60320 C14 |
Input Voltage | AC 230 V |
Output Current | +3.3V - 15 A | +5V - 15 A | +12V - 16 A |
Output Voltage | +3.3, +5, +12 V |
Power Capacity | 250 Watt |
Power Output Connectors Details | 1 x power 24 pin ATX | 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section | 3 x 15 pin Serial ATA power |
Miscellaneous | |
Cables Included | Power cable - external - 1 m |
Compliant Standards | RoHS, REACH |
Cooling System | 80 mm fan |
Features | Overheat protection, overcurrent protection, overvoltage protection, overpower protection, undervoltage protection, short-circuit protection |
MTBF | 100,000 hours |
Manufacturer Warranty | |
Service & Support | Limited warranty - 2 years |
Environmental Parameters | |
Max Operating Temperature | 50 °C |
Min Operating Temperature | 5 °C |
Dimensions & Weight | |
Depth | 17.5 cm |
Height | 6.5 cm |
Weight | 836.4 g |
Width | 8.5 cm |
Dimensions & Weight (Shipping) | |
Shipping Depth | 25.2 cm |
Shipping Height | 6.8 cm |
Shipping Weight | 846.4 g |
Shipping Width | 11 cm |
