Product no 995833014
Model AEROPGSVX-800PLUS-80
Brand AeroCool
EAN 4713105962819
Weight 1.6 kg
Produktbeskrivelse | AeroCool VX PLUS 800 - strømforsyning - 800 Watt |
Enhedstype | Strømforsyning - aktiv Power Factor Correction (PFC) - intern |
Specifikationsoverensstemmelse | ATX12V 2.3 |
Indgangspænding | AC 230 V |
Udgangspænding | +3.3, +5, ±12 V |
Strømkapacitet | 800 Watt |
Output Current | +3.3V - 22 A<br>+5V - 18 A<br>+12V - 58 A<br>-12V - 0.3 A<br>+5VSB - 2.5 A |
Output-stikforbindelser | 1 x strøm 24 pin ATX med aftagelig 4 pin sektion<br>1 x strøm 8 pin +12 V med aftagelig 4 pin sektion<br>6 x 15 pin Serial ATA strøm<br>4 x 4-PIN intern strøm<br>1 x 4-PIN mini-strømforsyningsforbinder<br>4 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion |
Kølesystem | 120 mm ventilator |
General | |
---|---|
Device Type | Power supply - active Power Factor Correction (PFC) - internal |
PSU Form Factor | ATX |
Specification Compliance | ATX12V 2.3 |
Power Device | |
Frequency Required | 47 - 63 Hz |
Input Voltage | AC 230 V |
Output Current | +3.3V - 22 A | +5V - 18 A | +12V - 58 A | -12V - 0.3 A | +5VSB - 2.5 A |
Output Voltage | +3.3, +5, ±12 V |
Power Capacity | 800 Watt |
Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section | 1 x power 8 pin +12V with detachable 4 pin section | 6 x 15 pin Serial ATA power | 4 x 4 pin internal power | 1 x 4 pin mini-power connector | 4 x 8 pin PCI Express power with detachable 2 pin sect |
Miscellaneous | |
Compliant Standards | FCC, RoHS, ErP Ready, EAC |
Cooling System | 120 mm fan |
Features | Overvoltage protection, overpower protection, undervoltage protection, short-circuit protection, single 12V rail, non-modular, Surge & Inrush Protection (SIP) |
