Teltonika RUT951 Trådløs router DIN monterbar på skinne Overflademonterbar
Teltonika RUT951 - - trådløs router - - WWAN 3-port switch - Wi-Fi - 2,4 GHz - 3G, 4G - DIN monterbar på skinne, overflademonterbar
1 545,00DKK1 236,00DKK excl. VAT
-
Product no 1000488321
Model RUT951000000
Brand Teltonika
EAN 4779051840168
Weight 0.287 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | Teltonika RUT951 - trådløs router - WWAN - Wi-Fi - 3G, 4G - DIN monterbar på skinne, overflademonterbar |
| Enhedstype | Trådløs router - trådløs mobilmodem - 3-port switch (integreret) |
| Pakningstype | DIN monterbar på skinne, overflademonterbar |
| Mobilprotokol | GSM, FDD LTE, TDD LTE |
| Generation | 3G, 4G |
| Mobilbånd | LTE B3, LTE B7, LTE B20, LTE B1, LTE B8, LTE B40, LTE B41, LTE B28A |
| Antal WAN porte | 1 |
| Dataforbindelsesprotokol | Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Frekvensbånd | 2,4 GHz |
| Kapacitet | Samvirkende tilslutninger: 100<br>IPSec VPN-tunneler: 4 |
| Netværks/overføselsprotokol | TCP/IP, PPTP, UDP/IP, L2TP, NTP, ICMP/IP, IPSec, PPPoE, ARP, SMTP, FTP, DHCP, DNS, DDNS, HTTP, HTTPs, IPv4, IPv6, Telnet |
| Routingprotokol | RIP-1, RIP-2, BGP, VRRP, NHRP, OSPFv2, statisk IP routing, GRE |
| Protokol til fjernadministration | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, SSH-2, CLI, TR-069, JSON-RPC, Modbus, NTP, MQTT, RADIUS |
| VoIP-protokoller | H.323, SIP |
| Egenskaber | Firewallbeskyttelse, NAT-understøtning, VPN support, aktivitet, WOL, auto-uplink (auto MDI/MDI-X), ALG-understøttet, E-mail advarsel, MAC-adresse-filtrering, Tilgangspunkt, drift, firmware kan opgraderes, DDos attack beskyttelse, WMM support, resultat register, QoS, IPSec NAT-T, DMVPN, SMS alarmer, port fremsendelse, nulstillingsknap, DHCP videresendelse, SNMP fælde, monterbar på DIN-skinne, GRE tunneling, FOTA, mærket VLAN, SYN Flooding, Captive Portal, systemlog, Web Filtering, Hotspot Access Point Capability, DMZ-support, portbaseret VLAN, sort liste, hvidliste, brotilstand, PPP, OpenVPN-klient, OpenVPN server, aluminiumskabinet, VoIP-gennemløbssupport |
| Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, WiFi-certificeret, IEEE 802.11e, IEEE 802.11n, UPnP |
| Effekt | AC 100-240 V |
| Dimensioner (B x D x H) | 11 cm x 10 cm x 5 cm |
| Vægt | 287 g |
| Lokalisering | Thailand, Korea, Mellemøsten, Afrika, Europa |
| General | |
|---|---|
| Authentication Method | Secure Shell (SSH), RADIUS, X.509 certificates, Radio Service Set ID (SSID), Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
| Capacity | Concurrent connections: 100 | IPSec VPN tunnels: 4 |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11e, IEEE 802.11n, UPnP, CCC, FCC, RoHS, FCC CFR47 Part 15, WEEE, ANATEL, FCC CFR47 Part 15 C, REACH, PTCRB, DNV, GCF, IP30, EAC, EN 61000-4-2:2009, EN 61000-4-5:2006, EN |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Device Type | Wireless router - 3-port switch (integrated) |
| Enclosure Type | DIN rail mountable, surface-mountable |
| Encryption Algorithm | DES, Triple DES, RC2, CAST5, TLS, SSL 3.0, PEAP, TKIP, WPA-PSK, AES-CCMP, 128-bit AES, 192-bit AES, 256-bit AES, WPA2-PSK, WPA2-Enterprise, IKEv2, WEP, 256-bit AES-CBC, 128-bit AES-CBC, 192-bit AES-CBC, IKEv1 |
| Features | Firewall protection, NAT support, VPN support, load balancing, wake on LAN (WOL), auto-uplink (auto MDI/MDI-X), ALG support, E-mail alert, MAC address filtering, Access Point operational mode, firmware upgradable, DDos attack prevention, Wi-Fi Multim |
| Flash Memory | 16 MB |
| Frequency Band | 2.4 GHz |
| Network / Transport Protocol | TCP/IP, PPTP, UDP/IP, L2TP, NTP, ICMP/IP, IPSec, PPPoE, ARP, SMTP, FTP, DHCP, DNS, DDNS, HTTP, HTTPs, IPv4, IPv6, Telnet |
| Processor | 1 x MediaTek MT7628 580 MHz |
| RAM | 128 MB DDR2 SDRAM |
| Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, SSH-2, CLI, TR-069, JSON-RPC, Modbus, NTP, MQTT, RADIUS |
| Routing Protocol | RIP-1, RIP-2, BGP, VRRP, NHRP, OSPFv2, static IP routing, GRE |
| Status Indicators | Power, signal strength, WAN, LAN |
| Communications | |
| Cellular Band | LTE B3, LTE B7, LTE B20, LTE B1, LTE B8, LTE B40, LTE B41, LTE B28A |
| Cellular Protocol | GSM, FDD LTE, TDD LTE |
| Generation | 3G, 4G |
| Max Transfer Rate | 150 Mbps |
| Type | Wireless cellular modem |
| IP Telephony | |
| VoIP Protocols | H.323, SIP |
| Internet of Things (IoT) | |
| Communications Technology | LTE Cat 4 |
| Internet of Things (IoT) Compatible | Yes |
| Expansion / Connectivity | |
| Expansion Slots | 2 (total) / 2 (free) x SIM |
| Interfaces | LAN: 3 x 10Base-T/100Base-TX - RJ-45 | WAN / LAN: 1 x 10Base-T/100Base-TX - RJ-45 | 1 x DO | 1 x DI | Antenna: 2 x SMA | Antenna: 2 x RP-SMA |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 4 |
| Power | |
| Power Device | External power adapter - 9 Watt |
| Voltage Required | AC 100-240 V |
| Miscellaneous | |
| Cables Included | 1 x network cable - 1.5 m |
| Included Accessories | 2 x Wi-Fi antennas, 2 x LTE antennas, SIM card adapter kit |
| Localization | Thailand, Korea, Middle East, Africa, Europe |
| Software / System Requirements | |
| OS Provided | RutOS |
| Dimensions & Weight | |
| Depth | 10 cm |
| Height | 5 cm |
| Weight | 287 g |
| Width | 11 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Max Operating Temperature | 75 °C |
| Min Operating Temperature | -40 °C |
