Product no 998946744
Model 10122195
Brand BlueWalker
EAN 4260074982862
Weight 28.4 kg
Produktbeskrivelse | PowerWalker VFI 3000 ICT IoT - UPS - 3000 Watt - 3000 VA |
Enhedstype | UPS - ekstern |
Vægt | 26.4 kg |
Udgangspænding | AC 200/208/220/230/240 V ± 1% |
Strømkapacitet | 3000 Watt / 3000 VA |
Input-stik | 1 x strøm IEC 60320 C20 |
Output-stikforbindelser | 8 x power IEC 60320 C13<br>1 x strøm IEC 60320 C19 |
Batteri | - 9 At |
Antal batterier | 6 |
Netværk | Ethernet, RS-232, USB |
Dimensioner (B x D x H) | 19.2 cm x 42.8 cm x 31.8 cm |
General | |
---|---|
Device Type | UPS - external |
Power Device | |
Efficiency | 93% at 100% Load |
Frequency Required | 45 - 55 / 54 - 66 Hz |
Input Connectors | 1 x power IEC 60320 C20 |
Input Voltage Range | AC 160 - 300 V |
Output Voltage | AC 200/208/220/230/240 V ± 1% |
Output Waveform | Sinewave |
Power Capacity | 3000 Watt / 3000 VA |
Power Factor (PF) | 0.99 |
Power Output Connectors Details | 8 x power IEC 60320 C13 | 1 x power IEC 60320 C19 |
Total Harmonic Distortion (THD) | 5 % |
UPS Technology | On-line |
Battery | |
Capacity | 9 Ah |
Quantity | 6 |
Recharge Time | 3 hours |
Transfer Time | 0 ms |
Voltage Provided | 12 V |
Networking | |
Remote Management Interface | Ethernet, RS-232, USB |
Expansion / Connectivity | |
Expansion Slots | 1 (total) / 1 (free) x Intelligent Slot |
Interfaces | 1 x management (USB) | 1 x management (RS-232) | 1 x EPO (emergency power off) |
Miscellaneous | |
Cables Included | USB cable - external | 2 x power cable (IEC) - external |
Features | Emergency power off, LCD display, overload protection, Human Interface Device (HID) support |
Software / System Requirements | |
Software Included | Winpower |
Environmental Parameters | |
Humidity Range Operating | 0 - 95% (non-condensing) |
Max Operating Temperature | 45 °C |
Min Operating Temperature | 0 °C |
Sound Emission | 50 dB |
Dimensions & Weight | |
Depth | 42.8 cm |
Height | 31.8 cm |
Weight | 26.4 kg |
Width | 19.2 cm |
Dimensions & Weight (Shipping) | |
Shipping Depth | 33 cm |
Shipping Height | 47.5 cm |
Shipping Weight | 28.9 kg |
Shipping Width | 59 cm |
