Product no 993490423
Model ATP200-EU0102F
Brand ZyXEL Communications
EAN 3540260177465
Weight 2.29 kg
Produktbeskrivelse | Zyxel ZyWALL ATP200 - sikkerhedsudstyr - cloud-administreret |
Enhedstype | Sikkerhedsudstyr |
Formfaktor | Ekstern |
Dataforbindelsesprotokol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Præstation | Firewall-gennemløb: 2 Gbps<br>VPN-gennemløb: 500 Mbps<br>Indtrængningsdetektion og præventions-gennemløb: 1,2 Gbps<br>Antivirus kapacitet: 450 Mbps<br>Unified Threat Management (UTM) kapacitet: 450 Mbps |
Kapacitet | Sideløbende TCP-sessioner: 600000<br>Sideløbende SSL VPN brugere: 10<br>Virtuelle grænseflader (VLANs): 16 |
Protokol for digital signaltransmission | H.323, SIP |
Dimensioner (B x D x H) | 27.2 cm x 18.7 cm x 3.6 cm |
Vægt | 1.4 kg |
Producentgaranti | 1 års garanti |
General | |
---|---|
Depth | 18.7 cm |
Device Type | Security appliance |
Height | 3.6 cm |
Weight | 1.4 kg |
Width | 27.2 cm |
Networking | |
Authentication Method | RADIUS, X.509 certificates, LDAP, Active Directory, Extensible Authentication Protocol (EAP), XAUTH authentication |
Capacity | Concurrent TCP sessions: 600000 | Concurrent SSL VPN users: 10 | Virtual interfaces (VLANs): 16 |
Cloud-Managed | Yes |
Compliant Standards | IEEE 802.1Q, IEEE 802.1x, X.509 |
Connectivity Technology | Wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Encryption Algorithm | DES, Triple DES, MD5, IKE, SSL, SHA-1, PKI, 256-bit AES, IKEv2, SHA-2 |
Features | Firewall protection, routing, VPN support, PAT support, SNAT support, Syslog support, Stateful Packet Inspection (SPI), DoS attack prevention, content filtering, ALG support, IPv6 support, DDos attack prevention, IPSec Virtual Private Network (VPN), |
Form Factor | External |
Network / Transport Protocol | L2TP, IPSec, PPPoE, SMTP, FTP, DNS, POP3, DDNS, DHCPv6 |
Performance | Firewall throughput: 2 Gbps | VPN throughput: 500 Mbps | Intrusion detection and prevention throughput: 1.2 Gbps | Antivirus throughput: 450 Mbps | Unified Threat Management (UTM) throughput: 450 Mbps |
Remote Management Protocol | SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH |
Routing Protocol | OSPF, RIP-1, RIP-2, BGP, static IP routing, GRE, policy-based routing (PBR) |
Status Indicators | Power, system, link/activity |
Communications | |
Digital Signaling Protocol | H.323, SIP |
Expansion / Connectivity | |
Interfaces | 4 x 1000Base-TX - RJ-45 (LAN / DMZ) | 2 x 1000Base-TX - RJ-45 (WAN) | 1 x - SFP (mini-GBIC) | 2 x USB 3.0 - Type A | 1 x console - DB-9 |
Miscellaneous | |
Compliant Standards | BSMI, ICSA Firewall certified, C-Tick Class B, RoHS, EMC Class B, FCC Part 15 Class B, LVD 60950-1 |
MTBF | 529,688.2 hours |
Power | |
Power Consumption Operational | 13.3 Watt |
Power Device | External power adapter |
Dimensions & Weight (Shipping) | |
Shipping Depth | 24.7 cm |
Shipping Height | 7.3 cm |
Shipping Weight | 2.23 kg |
Shipping Width | 42.7 cm |
Manufacturer Warranty | |
Service & Support | Limited warranty - 1 year |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Max Operating Temperature | 40 °C |
Min Operating Temperature | 0 °C |
