Product no 306717
Model TL-SG1024D
Brand TP-LINK Technologies
EAN 6935364020620
Weight 2.07 kg
Produktbeskrivelse | TP-Link TL-SG1024D - switch - 24 porte - monterbar på stativ |
Enhedstype | Switch - 24 porte |
Pakningstype | Monterbar på stativ 1U |
Undertype | Gigabit Ethernet |
Porte | 24 x 10/100/1000 |
Præstation | Omkoblingskapacitet: 48 Gbps<br>Fremsendelsespræstation: 35.7 Mpps |
MAC adresse table størrelse | 8K indtastningshukommelse |
Jumborammesupport | 10KB |
Egenskaber | Datatransport, komplet duplex ydeevne, auto-negotiation, auto-uplink (auto MDI/MDI-X), gem og send, blæserløs |
Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3ab, IEEE 802.3x |
Effekt | AC 120/230 V (50/60 Hz) |
Dimensioner (B x D x H) | 44 cm x 18 cm x 4.4 cm |
General | |
---|---|
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3ab, IEEE 802.3x |
Device Type | Switch - 24 ports |
Enclosure Type | Desktop, rack-mountable 1U |
Features | Flow control, full duplex capability, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, fanless |
Jumbo Frame Support | 10KB |
MAC Address Table Size | 8K entries |
Performance | Switching capacity: 48 Gbps | Forwarding performance: 35.7 Mpps |
Ports | 24 x 10/100/1000 |
Status Indicators | Power, 100M device connected, 1000M device connected, link/activity |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 24 x 1000Base-T RJ-45 |
Power | |
Power Device | External power adapter |
Voltage Required | AC 120/230 V (50/60 Hz) |
Miscellaneous | |
Compliant Standards | FCC, RoHS |
Included Accessories | Rubber feet |
Rack Mounting Kit | Included |
Dimensions & Weight | |
Depth | 18 cm |
Height | 4.4 cm |
Width | 44 cm |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Humidity Range Storage | 5 - 90% (non-condensing) |
Max Operating Temperature | 40 °C |
Max Storage Temperature | 70 °C |
Min Operating Temperature | 0 °C |
Min Storage Temperature | -40 °C |
