Product no 990160429
Model TL-SG108PE
Brand TP-LINK Technologies
EAN 6935364094744
Weight 0.91 kg
Produktbeskrivelse | TP-Link Easy Smart TL-SG108PE - switch - 8 porte - smart |
Enhedstype | Switch - 8 porte - smart |
Undertype | Gigabit Ethernet |
Porte | 4 x 10/100/1000 (4 PoE+) + 4 x 10/100/1000 |
Power Over Ethernet (PoE) | PoE+ |
PoE-budget | 64 W |
Præstation | Fremsendelsespræstation: 11.9 Mpps |
Kapacitet | Virtuelle grænseflader (VLANs): 32 |
MAC adresse table størrelse | 4K indtastningshukommelse |
Jumborammesupport | 15KB |
Egenskaber | Datatransport, auto-negotiation, VLAN-understøttet, auto-uplink (auto MDI/MDI-X), IGMP snooping, portspejling, gem og send, QoS, Cable Diagnostics Function, blæserløs, løkkeforebyggelse, DSCP support, 1,5 MB pakkebuffer, Storm Control, Link Aggregation |
Overensstemmelsesstandarder | IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at |
Effekt | AC 120/230 V (50/60 Hz) |
Systemkrav | Microsoft Windows Vista / XP / 7, Windows 8 / 8.1, Windows 10 |
General | |
---|---|
Capacity | Virtual interfaces (VLANs): 32 |
Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at |
Device Type | Switch - 8 ports - smart |
Enclosure Type | Desktop |
Features | Flow control, auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, store and forward, Quality of Service (QoS), Cable Diagnostics Function, fanless, loop prevention, DiffServ Code Point (DSCP) support, 1.5MB pa |
Jumbo Frame Support | 15KB |
MAC Address Table Size | 4K entries |
Performance | Forwarding performance: 11.9 Mpps |
PoE Budget | 64 W |
Ports | 4 x 10/100/1000 (4 PoE+) + 4 x 10/100/1000 |
Power Over Ethernet (PoE) | PoE+ |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 4 x 1000Base-T RJ-45 PoE+ - 15.4 W | 4 x 1000Base-T RJ-45 |
Power | |
Power Device | External power adapter |
Voltage Required | AC 120/230 V (50/60 Hz) |
Miscellaneous | |
Compliant Standards | FCC, RoHS |
Software / System Requirements | |
OS Required | Microsoft Windows Vista / XP / 7, Windows 8 / 8.1, Windows 10 |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Humidity Range Storage | 5 - 95% (non-condensing) |
Max Operating Temperature | 40 °C |
Max Storage Temperature | 70 °C |
Min Operating Temperature | 0 °C |
Min Storage Temperature | -40 °C |
